Bell mouth inlet, Quadro square body static mixer nozzle for 200ml, 400ml and 600ml dual component epoxy type cartridges. Luer type nozzle outlet design that can be used with all luer precision needle tips.

These mixer nozzles are suitable for 1:1 and 2:1 ratio two-component materials. They have green inner elements and are constructed of high grade polypropylene. High quality mixer nozzles for use with twin cartridges. All items are industrial grade safe and silicone free. 5.0mm ID x 24 mixing elements.

---

Part ID: MCQ 05-24L - 300002
Material: Polypropylene
Colour: Natural Outer, Green Elements
Inner Diameter: 5.3mm
Outer Diameter: 8.0mm
Elements: 24
Length: 127mm
Volume in Nozzle: 3.46ml
Details: Industrial Grade, Silicone Free
Commodity Code: 39269097
Origin: Europe
Brand: Sulzer Mixpac MedMix

---

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

---

• Part ID: MCQ 05-24L - 300002 Material: Polypropylene
• Colour: Natural Outer, Green Elements
• Inner Diameter: 5.3mm
• Elements: 24
• Length: 127mm
• Volume in Nozzle: 3.46ml
• Details: Industrial Grade, Silicone Free


  Scan for Datasheet

High density moulded static mixer nozzles with bell attachment to cartridges or machines. Stepped end design for direct dispensing or attachment of reducer fitting when using small luer lock needle tips. Silicone free and industrial grade.

All nozzles are safe for use up to 100 psi pressure. Nozzles are precision manufactured for  industrial use. All nozzles are certified silicone-free to prevent contamination of any liquids dispensed from them.
