Super lightweight manual twin cartridge gun. Suitable for use with 600ml dual cartridges.
For epoxies, adhesives and many other materials that are supplied in 600ml type dual side-by-side 1:1 ratio cartridges with the use of a static mixing nozzle. The lightweight and durable construction of these dual guns make them well suited for many assembly operations in various markets such as aerospace, electronics, construction and automotive. This is a very lightweight hand trigger operated cartridge gun.
Use with Mixpac, TAH type and other 600ml 1:1 dual side-by-side cartridges. Top loading system allows more versatility with cartridge insertion and with cartridge size. The AD Series guns are covered by a 1 year warranty and feature a wear compensating device.
Features:
12:1 Thrust Ratio
For Use with 600ml 1:1 Dual Ratio Cartridges
Precision Sintered Friction Plate
Easy Release Star-Burst Reverse Gripping Plate
Lightweight Materials
Slide in/Top Load
Specifications:
Lightweight: 0.9kg
Cartridge Holder Length: 185mm
Maximum Thrust: 1.2kN
Handle Material: High Density Nylon
Frame Material: High Density Nylon
Cartridge Capacity: 600mL
Cartridge Ratio: 1:1
Mechanical Advantage Ratio: 12:1
Viscosity: Low
Standard Colour: Yellow
Commodity Code: 90289090
Origin: Asia
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
- Part ID: AD600-1 Materials: Reinforced Nylon, Polypro, Steel, Zinc
- Colour: Blue Size: 600ml 1:1 Weight: 0.9kg Warranty: 1 Year
This gun is compatible with 600ml 1:1 ratio dual cartridge sets.
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- 12:1 Thrust Ratio
- For Use with 600ml size Mix Ratio of 1:1 Only Precision Sintered Friction Plate
- Easy Release Star-Burst Reverse Gripping Plate
- Hammered Finish Zinc Alloy Handle with Comfort Grip
- Slide in/Side Load
|
|
|
|
|
|
|
|
|
