3cc Clear Barrel White Piston Kit 7030LL1NW-1000
Product Code: 7030LL1NW-1000
Price: £434.00
Description
The 700
Series Premier dispensing syringe barrels are silicone and chloride-
free and designed to work with dispensing equipment - either manually or
on a pneumatic dispenser. The syringe barrels are made from low
friction polypropylene to ensure accuracy, repeatability and
productivity. Features a double Helix Luer lock for secure dispense tip attachment. Supplied in sealed packs. Natural (clear) colour.
Plastic wiper pistons available for all barrel sizes as well as end caps and adapter assemblies. Use a piston for thick pastes, gels, etc. to prevent air pushing through materials inside the barrel. Supplied with white wiper piston in the kit. Maximum operating pressure is 100 psi (6.9bar). These parts ship direct from stock. Pack of 1000 barrels and 1000 pistons.
Barrel Material: High Density Polypropylene (HDPP)
Barrel Volume Capacity: 3cc (3ml)
Barrel Total Overall Length: 2.981" (75.72mm)
Barrel Outer Diameter: 0.45" (11.42mm)
Barrel Inner Diameter: 0.38" (9.58mm)
Barrel Flange Width: 1.23" (31.24mm)
Barrel Tip Hole Outlet Size: 0.118" (3.00mm)
Barrel Colour: Natural (Clear)
Piston Material: Low Density Polyethylene (LDPE)
Piston Colour: White (Opaque)
Maximum Pressure: 100 PSI
Mfg. Part: 7030LL1NW-1000
Commodity HS Code: 39269097
Details: Silicone-Free, Industrial Grade
Brand: TSI
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
Plastic wiper pistons available for all barrel sizes as well as end caps and adapter assemblies. Use a piston for thick pastes, gels, etc. to prevent air pushing through materials inside the barrel. Supplied with white wiper piston in the kit. Maximum operating pressure is 100 psi (6.9bar). These parts ship direct from stock. Pack of 1000 barrels and 1000 pistons.
Barrel Material: High Density Polypropylene (HDPP)
Barrel Volume Capacity: 3cc (3ml)
Barrel Total Overall Length: 2.981" (75.72mm)
Barrel Outer Diameter: 0.45" (11.42mm)
Barrel Inner Diameter: 0.38" (9.58mm)
Barrel Flange Width: 1.23" (31.24mm)
Barrel Tip Hole Outlet Size: 0.118" (3.00mm)
Barrel Colour: Natural (Clear)
Piston Material: Low Density Polyethylene (LDPE)
Piston Colour: White (Opaque)
Maximum Pressure: 100 PSI
Mfg. Part: 7030LL1NW-1000
Commodity HS Code: 39269097
Details: Silicone-Free, Industrial Grade
Brand: TSI
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
Features
- Silicone and chloride free Industrial grade safe to 100 psi
- Resistant to aggressive fluids and solvents
- Wide flanges for secure air attachment
- Luer lock tip attachment on barrel
- Dual blade white wiper piston
- Zero draft inner walls for precision
