Description
A 25 gauge brush tip suited to dispensing most fluids. Certified silicone-free and industrial grade safe for use to 100 psi. Use these double helix Brush Tips for spread applications such as glues and other materials. Brush is made of stiff nylon. Supplied in a sealed pack of 10.
High quality products for multi-use. Suitable for use with all dispensing guns, pneumatic dispensers, dosing valves and XYZ robots.
The tip features a slightly tapered internal design where the shaft meets the hub to improve fluid flow and reduce any restriction. This allows for a lower pressure to be used for dispensing adhesives, inks and other fluids.
Part ID: AD-1001-25BTPK
Material: Polyethylene/ Nylon
Colour: Silver/ Yellow bristles
Inner Diameter: 0.25mm
Length: 1.5" (2.0" incl. brush)
Details: Industrial grade, Silicone Free
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all
assembly fluids - from watery liquids, solvents, primers and activators
through to thick pastes, sealants, silicones, gels and epoxies.
Features
- Soft or stiff bristle nylon versions
- Silicone free plastics
- Smooth flow internal hub design
- Safety lock helix threaded hubs
- Industrial grade safe to 100 psi
- Individually or in packs of 12
- Use with all syringes, bottles and valves
