Luer lock assorted syringe tip component kit SA8477 Adhesive Dispensing Ltd

Description

Hand operated manual syringe assembly complete with luer lock tip attachment, cap seal supplied with 14 gauge polypro dispensing tips. A multi purpose evaluation pack of clear 20ml/ 20cc manual syringes with luer lock dispensing tips. Graduated syringe barrel includes plunger rod and rubber piston. Luer lock twist-on tip attachment. Tips are 1/2" long, 1" long and 1.5" long. Polypro tips have a flexible white tube.

Non sterile manual 20cc/ 20ml size syringe barrel assembly. Natural (clear) barrel high density polypro with 0.2ml markings. Luer lock for twist on attachment of needle tips. These syringes are industry compliant low friction polypropylene. Suited for use with most fluids, adhesives, solvents, primers, inks, paints, lubricants and activators.

PP series polypro tips are designed to work with all luer lock and luer slip syringe barrels and fittings. They are fully compatible with most fluids, adhesives, solvents and chemicals. Tips are colour coded for gauge size. The tip features a slightly rounded internal design where the shaft meets the hub to improve fluid flow and reduce flow restriction. This allows for a lower pressure to be used for dispensing of liquids and pastes. 14 gauge polypro tips have a 1.4mm inner diameter tube.

Please note that these items are shipped in sealed and labelled packs direct from stock.

The kit includes: -

Clear syringe assembly luer lock 20ml or 20cc size x 5
Tip cap seal orange x 5
15 GA Polypro Tip 0.5" long Olive 1.40mm ID x 5
15 GA Polypro Tip 1" long Olive 1.40mm ID x 5
15 GA Polypro Tip 1.5" long Olive 1.40mm ID x 5

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Features

Precision burr free tubing on tips
Luer lock syringes for twist on secure tip attachment
Unmarked syringe barrels
Industrial style syringes - not medical
Double helix luer lock needle tips blunt end
Colour coded tip hubs
For use all fluids, adhesives and solvents
