200ml Twin-Pack Cartridge Dispense System DSX-200
Product Code: F200PN
Price: £2,495.00
Description
The DSX-200 dual cartridge dispense systems are excellent, cost-effective solutions for low-volume mixing and dispensing of 2-component materials supplied in 400 ml dual cartridges. These bench-mounted systems are simple to set up and program for accurate 2-component dispensing of epoxies, silicones, urethanes and acrylics in potting, encapsulation, and bonding applications.
The systems utilise a pneumatically actuated piston, controlled by a pressure regulator to allow for consistent pressure control and metering. Supplied with the a pinch tube valve and position control mounting assembly to ensure a drip-free cut-off and consistent results when dispensing low viscosity materials. Can be used without the pinch valve for high viscosity materials direct from the mixer nozzle.
The Twin-Pack Cartridge Dispense System reduces stress and operator fatigue and ensures accurate dispensing with less rejects and/or wasted material.
A foot pedal operated digital dispenser is included for repeatable timed cycling or manual deposits. A universal cartridge holder for 200ml cartridges may be swivelled at any angle for a comfortable bench operating position. Alternatively the system can be used in conjunction with a dispensing robot as a convenient method of interfacing a cartridge feed for automatic deposition of mixed material. Please note that this is the 400ml version only which can handle all 200ml 1:1, 2:1, 4:1 & 10:1 ratio cartridges.
Item Number Description
DSX-200 200 ml Dual Cartridge Dispense System
FEATURES
• Drip-free and accurate dispense results
• Simple set up and operation
• Adjustable dispense height and angle
• DSX-200 compatible with 1:1, 2:1, 4:1 and 10:1 ratio C-Style and F-Style 200ml cartridges
• Adjustable dispense volumes
• 3-way pneumatic lever control valve
• DC50 dispenser and 710PT-U valve included with DSX-200
• Heavy duty industrial design
BENEFITS
• Anchoring holes located in the base plate to secure onto the workbench for maximum stability (hardware included)
• Suitable for both low to high viscosity fluids
• Dispensing from dual cartridges can be completed hands-free for improving process control
• Additional mounting points for easy attachment of a fixture for positional dispense accuracy
• Modular design allows for dispense equipment to be easily transferred onto an XYZ dispensing robot
• 3-way lever valve ensures safe control of piston retraction and cartridge changeover
SPECIFICATIONS
Item Number: DSX-200
Air Input: 70-100 PSI
Air Output: 1 - 100 PSI
Air Input Connection: 1/4" OD
Cycle: Manual or Timed
Input: AC to Power Supply 100 - 240 VAC, 50/60 Hz
Output: DC from Power Supply 24V DC - 1 Amp
Timer: 0.008 - 99.99s
Noise Level: 83 dBa
Standards: RoHS Compliant, CE
Warranty: 1 Year
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
Features
- Fits all 200ml 1:1, 2:1, 4:1 & 10:1 ratio cartridges
- Easy cartridge load and unload
- Controlled repeat shot or beads
- Hands-free stand mounted
- Optional TS1212 valve can be added
- Built in adjustable air regulator
