10oz syringe barrel filling station

Description

An efficient method of transferring greases, epoxies, silicones, solder pastes and other thixotropic materials into a disposable syringe barrel. This barrel loader is supplied with a pneumatic adjustable timed benchtop dispenser to control the operation.

The model 1000-10D barrel loader is for pre-filled 10oz (310cc/ 310ml or 1/10 gallon size) sealant and silicone cartridges, which are placed inside a sealed container mounted on the stand. The barrel attachment assembly is threaded to accept luer lock barrels. Activating the pneumatic dispenser once connected to the air line causes the material to rise inside the barrel. This method simplifies loading and reduces the possibility of entrapped air in the fluid.

The 1000-10D includes pneumatic bench mounted dispenser with 0-100 psi adjustable regulator/ gauge, benchtop cartridge base stand, retainer bracket support, 10oz retainer and air cap, five (5) empty 10oz cartridge and plungers, an outlet cap and special barrel attachment assembly. The 10oz (310cc/ml) cartridges are filled with material of choice.

This system can also be used with pre-filled silicone/ sealant/ RTV tubes 310ml (1/10 GAL) size. Special fittings are included to adapt the silicone tube nozzle end and convert to syringe barrel twist-on attachment. The digital dispenser controlling this system allows timed filling to each syringe barrel to eliminate guesswork and improve repeatibility. This system is operated by electric foot switch (supplied).

Part ID: 1000-10D
Materials: Polyethylene/ Steel/ Nylon
Capacity: 10oz/ 310cc or 310ml or 1/10 GAL
Weight: 4kg
Max Pressure: 100 PSI
Warranty: 12 Months

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Features

For 10oz cartridges
Includes adjustable bench mounted timed pneumatic dispenser
Bottom fills syringes to reduce air
Supplied with components
Safe for use up to 100 psi
Quick and easy setup
Industrial grade safe
For pastes, gels, silicones and sealants
