Large 12oz Digital Syringe Filling Station 1000-12D
Product Code: 1000-12D
Price: £475.00
Description
The model 1000-12D barrel loader is for pre-filled 12oz cartridges, which are placed inside a vertical container mounted on the stand. The barrel attachment assembly is threaded to accept luer lock barrels. Activating the pneumatic dispenser once connected to the air line causes the material to rise inside the barrel. This method simplifies loading and reduces the possibility of entrapped air in the fluid.
The 1000-12D includes pneumatic bench mounted digital timed dispenser with 0-100 psi adjustable regulator/ gauge, bench top cartridge base stand, retainer bracket support, 12oz retainer and air cap, five (5) empty 12oz cartridge and plungers, an outlet cap and special barrel attachment assembly. The 12oz (355cc/ml) cartridges are filled with material of choice.
The digital dispenser controlling this system allows timed filling to each syringe barrel to eliminate guesswork and improve repeatibility. A teach function allows the amount to be filled to each syringe to be setup rapidly.
Part ID: 1000-12D
Materials: Polyethylene/ Steel/ Nylon
Capacity: 12oz/ 355cc or 355ml
Weight: 4kg
Max Pressure: 100 PSI
Warranty: 12 Months
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
Features
- For 12oz cartridges
- Includes adjustable bench mounted timed pneumatic dispenser
- Bottom fills syringes to reduce air
- Supplied with components
- Safe for use up to 100 psi
- Quick and easy setup
- Industrial grade safe
- For pastes, gels, silicones and sealants
