500 Gram Pressure Pot 0-60 psi regulator TS1215
Product Code: TS1215
Price: £0.00
Description
* Please note - this product is now obsolete. Use the TS1205 similar version pressure pot.
TS1215 is a compact size pressure
pot for use with most cyanoacrylates, UV's, anaerobics and many other low to
medium viscosity fluids. No pouring is needed; you just drop the glue bottle
right into the tank, seal with wing nuts, and pressurise. Constant regulated
air pressure then forces the liquid from the bottle placed inside through
tubing in the lid up to the point of dispense.
This system accepts adhesive bottles 250gm and 500gm size or containers placed inside the chamber or use fluids direct in any can or bottle that will fit. The TS1215 comes with built-in adjustable 0-30 psi regulator and comes with plastic feed tubing kit as well as a luer lock connector with dip tube for use with standard fluid lines.
Easy connect to any air supply using the air input fitting at the base. The product is UK manufactured and comes with a 12 month warranty against fault.
Material: Anodized Aluminium/ Steel
Colour: Black
Size: 4.50" W x 7.00" High
Chamber: 4.00" W x 6.00" High
Weight: 2.5kg
Max Pressure: 60 psi (4 BAR)
Warranty: 12 Months
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
Features
- 60 psi regulator - Ideal operating pressure for adhesives and solvents
- Fluid Outlet Port - On the lid for easy access
- Compact Size - Small footprint takes up less space
- Four knobs to open/close lid - For positive and uniform seal
- Pressure Gauge - Located on side for easy reading
- Pressure Regulator - Located on side for ease of access
- Relief Valve with Pull Ring - To depressurise after usage
- Black disposable polyethylene - Fluid lines can be changed quickly
- Ferrule - Disposable with tubing eliminates cleanup
- Hose Clip - Holds air line steady
- Tube Sizes - 1/4", 3/8" and 4mm fittings available
